Physio-Control Lifepak 9 – Microprocessor-based Defibrillator/Monitor for Efficient Cardiac Emergency Response
The Physio-Control Lifepak 9 is a sophisticated defibrillator/monitor equipped with a microprocessor for precise cardiac emergency response. With a user-friendly design, this defibrillation system offers both high and low energy selections, non-invasive pacing, cardioscope, and 3-lead and 5-lead ECG monitoring. The microprocessor adapts the energy required for defibrillation, making it versatile for adult and pediatric patients.
Key Features:
- Microprocessor-based unit with optimal pacing capabilities.
- Operates on both AC power and internal battery power for flexibility.
- Built-in recorder and 3-5 lead ECG monitoring for comprehensive patient data.
- Front panel push buttons for easy control of essential functions.
- Hands-free defibrillation with the included adaptor.
Specifications:
- Dimensions: Height – 35.2 cm, Width – 29.7 cm, Depth – 31 cm.
- Weight: 12.7 kg (28 lbs).
- Power Cord Length: 3m (10 Ft).
- Battery Type: Sealed lead-acid, 16 Vdc nominal, 3 Amp-hour.
- ECG Monitor: 3-5 lead options, heart rate display, and CRT monitoring.
- Defibrillator: Monophasic pulse waveform, energy selections from 1 to 360 Joules.
- Thermal Array Recorder: Paper size – 50mm wide x 30m (100 ft), paper speed – 25mm/second.
Experience efficient cardiac emergency response with the Lifepak 9, offering advanced features and precise energy delivery for optimal patient care.
